January 2024

  Dolph Microwave 1.2 Meter driveaway antenna for Ku/Ka dual band . Rugged packaging, robust wind performance, ease of operation and post-delivery customer support at a very competitive price.   1.2 Meter driveaway antenna is capable of transmitting and receiving in Ku/Ka-band frequencies simultaneously. and quick deploy with operational status achieved in less than 10 […]

  The ring- focus antenna is usually called the parabolic focal axis offset axisymmetric dual mirror antenna. Since the focal trajectory of the antenna is a circle, it is called the circular focus antenna.     The ring-focus antenna has its unique position in the satellite communication earth station antenna. Especially in the small and

  Quad-Ridged Horn Antenna is one of the wide-band antennas developed by Dolph Microwave. It covers different combined frequency bands within 0.1-40GHz, and is widely used in EMI / RFI testing, evaluation, and electronic monitoring. It can also be used as a feed for high-gain parabolic reflector antennas used in directional and monitoring.   Because

    The logarithmic periodic antenna is the main preferred form of the low frequency uwb directional antenna. The antenna family can cover octave bandwidth or even uwb bandwidth of nearly 100 octaves. The gain can be as high as 9dB. At ultra-low frequencies, a hybrid design is adopted to achieve a high integration of

    VSWR Test   Double Ridge WR650D High Power Termination   – Model: DH-650DRWHPL500PA   – Frequency Range: 6.5 – 18.0 GHz   – VSWR: ≤1.20:1   – Average Power: ≥500W     VSWR for Double Ridge WR650D High Power Termination   WR28 High Power Termination   – Model: DH-320WHPL500PA   – Frequency Range: 26.3 – 40.0 GHz

  The precision version is manufactured from brass and painted with attractive, hard wearing, epoxy paint finish as standard. Each adaptor is tuned to offer the highest possible performance over the full waveguide frequency band.   We the following precision WG to coax adaptors ready to be delivered!   Precision Version WaveGuide Coax Adapters

Waveguide Components Composite Dolph Microwave offers one of the most complete lines of composite twist-bends waveguide in the industry. Basic styles in many bends include miter and radius 90 bends, as well as acute and obtuse E and H plane bends in angles from 30 to 180. Our dual-E and offset bends were developed to

This Ku-band transmit reject filter is designed for Ku band satcoms transmitter applications for suppressing broad band noise in the receive band from a transmitter output. It fully rejects the transmit band (above) and virtually all undesired transmissions (below) the receive band. Specifications: Model number: DH-120WBPF82PMA Rejectband: 13.75 –14.5 GHz Passband: 10.70-12.75 GHz Insertion Loss:

We have cooperated with a customer on a batch of X-band high power waveguide terminations for radar system recently. Following is the product details before surface treatment and VSWR test which is ≤1.05:1. Features Waveguide terminations WR-22 to WR-650 Air cooling, water cooled and water terminations available. Units pressure tested to 30 psi. Low outgassing

  In order to provide the fastest products and services to our customers, Dolph Microwave stocked a series of products flexible twistable waveguide; the fastest delivery is on next day.     Flexible Twistable Waveguide   – Model: DH-137WEL1000MMC   – Freq. Range: 4.64-7.05 GHz   – VSWR: 1.1   – Insertion Loss: 0.18dB/m
