Dolph Microwave manufactures standard gain horn antennas specifically designs for utilization in emissions and immunity testing over the frequency range of 0.32 to 110 GHz. And, they offer high power handling capability, and low loss, also high directivity, and near constant electrical performance across a wide bandwidth, low gain variation across their operating frequency.
In a short, these horn antennas that are linear polarization, light weight and corrosion resistant. The most common Gain values available are 10, 15, 20, 25dB. Also, other gain values and Horn sizes are according to your requirement.
- Model: DH-100SGAH15(WR90)
- Frequency Range: 8.2-12.4 GHz
- Gain (Avg): 15 dB
- VSWR (Max.): 1.25:1(Flange) / 1.5:1(SMA/N-Type)
- Waveguide Type: WR90
- Interface: FBP100 (UBR100) / SMA/N-Type
- Size: 69.2*52.7*52.5 mm
- Material: Aluminum / Copper
- Inside finish: Conductive Oxidation / Silver plating
- Outside finish: Anticorrosion white paint
Any interested items, please contact.
