W-Band, 75-110GHz, WR10 Full band, Block Type Directional Couplers

Block type directional couplers are passive devices mainly used in the field of wireless technology. They couple the defined amount of electromagnetic power in the transmission line to the port, allowing the signal to be used in another circuit.

Block Type Directional Coupler

Dolph Microwave’s DH-900WBDC25PPPPC broadband directional coupler is a wide walled porous energy coupling device operating in the range of 75 to 110 GHz. This coupler provides a nominal coupling level of 25 dB, and the directional coupler is configured to have WR-10 waveguide and UG-387/U compatibility on all ports.

Block Type Directional Coupler

WR10 Waveguide Block Type Directional Coupler
Electrical Specifications
Model DH-900WBDC25PPPPC
Frequency Range 75.0-110.0 GHz
Coupling (dB) 25±1.0 dB
Main Line VSWR ≤1.1:1
Sec. Line VSWR ≤1.3:1
Directivity (dB) ≥20 dB
Port Style 4 Waveguide Ports
Coupling Port 2*UG-387/U
Flange UG-387/U
Material Cu
Surface Treatment Gold Plated
Surface Coating Black Paint
Size 74*22*28 mm
